Long Rod Screen Printing Machine

  • Model:EC-400H
  • Views:902
  • Fishing Rod Screen Printing Machine
  • Long Rod Screen Printing Machine  , Fishing Rod Screen Printer
    Inquiry Send Email

    Description

    This machine is designed for precise printing of slim, long shafts and Cylindrical forms which with smooth curve surface such as fish pole, golf clubs, cue, Golfball Rod,

    Fishing Rod, Water Pipe, and any kinds of long tube product printing with long printing size. It is  also featured by its 360 degree printing and one fixture is suitable for all diameter is
    within 130mm whole circle or half circle single color and multicolor printing.

    Feature
    1. Advanced computerized system control
    2. Built-in LED digital counter
    3. Suitable for printing on round, cylindrical, oval or flat project
    4. Pneumatically driven adopt from FESTO, can adjust the movement speed of each part
    5. Can be operated in manual and semi-auto mode to suit different worker's skill level.
    6. Horizontal movement of screen frame can be adjusted to fit your various printing needs.
    7. Squeegee/flood bar depth, pressure, speed, leveling, and stroke etc., are all adjustable to fit your various printing needs.
    8.Pneumatic components of Germany FESTO, ensure that the machine quality
    Specifications
    1. No. of color:1color (can be color-process)
    2. Max printing diameter: Ф130mm
    3. Max Printing area:380×1000mm
    4. Air pressure:6 Bar
    5. Air consumption:200 liter/min
    6. Power voltage: AC 110V/220V
    7. Power consumption:35 W
    8. Machine dimension:1430×1240×1510mm
    9. Machine weigh: 260kg
