Application: High Precision PCB , LCD LENS , Conductive film circuit , PMMA ect , all high precision printing products. Technical Parameter:
Workbench area: 300mm*400mm
Max Printing Area: 200mm*300mm
Max Screen Size: 450mm*620mm
Product Max Heigh : ≦180mm
Workbench Horizontal Precision: ±0.05
Overcolor Print Precision: ±0.01
Printing Pressure: 4.0-6.0Kgf/c㎡
Operation Air Pressure:0.3Mpa-0.5Mpa
Source Power: 1.5kw
Rated Voltage: 380V
Printing Speed: 960PCS/Hr
1.Printing Transmission ( Printing head left and right moving) adpots Panasonic brand servo motor drive,high precision linear lead rail and synchronous belt drive, PLC control and touch screen setting , speed equality and can be adjusted.
2. Printing head and screen frame up and down lifting is driven by Panasonic brand servo motor (Optional) or stepping motor. PLC control and touch screen setting , or frequency control,move steady.
3.The printing blate and ink-return blate with a airpressure adjusted device and can rugulate printing thickness.
4. Vacuum table strong suck power to fix printing.
5.With a up and down,left and right,front and back vernier device very convinient for register.With a safty device ,safe and reliable.
6.ECU centralized control by the microcomputer,easy to operation,flexible and convenient for maintenance.
