Description
Application:
Be applied to the flat pringting for
CD,nameplatestickers,credit card,Ceramic colored paper,wooden toy
puzzles and
membrane switches in electronic industry It is also applicable to the flat printing such
as golden and silver cardboardmetal sheet,and other products with the material of PVC,which have high requirement in overprinting.
Function
1.Aluminum alloy high strengthTtype worktable, convenient fixture installation
2.Four figures autiomatic counters inside.
3.Adjustable Print speed satisfies the different printing request.
4.Constant pressure device of the ink blade,made sure the pressure in the printing is steady.
5.High-precision printing platform with fine turning device.
6.Convenient pedal switch,simplicity of operation,maintenance friendly
7.Independent printing and ink-rerurn system.
Specification
1. Max printing area : 150x200mm
2. Max Screen size: 250 x350mm
3. Working table size: 120x250mm
4. Printing accuracy: 0.08mm
5. Max printing height: 80mm
6. Power: 220V/110V 50/60hz Power:40w
7. Air pressure: 4-6bar
7. Max printing speed: 1200-1500pcs/hour
8. Machine dimension: 800x370 x700mm
9. Machine NW: 40kg
Be applied to the flat pringting for
CD,nameplatestickers,credit card,Ceramic colored paper,wooden toy
puzzles and
membrane switches in electronic industry It is also applicable to the flat printing such
as golden and silver cardboardmetal sheet,and other products with the material of PVC,which have high requirement in overprinting.
Function
1.Aluminum alloy high strengthTtype worktable, convenient fixture installation
2.Four figures autiomatic counters inside.
3.Adjustable Print speed satisfies the different printing request.
4.Constant pressure device of the ink blade,made sure the pressure in the printing is steady.
5.High-precision printing platform with fine turning device.
6.Convenient pedal switch,simplicity of operation,maintenance friendly
7.Independent printing and ink-rerurn system.
Specification
1. Max printing area : 150x200mm
2. Max Screen size: 250 x350mm
3. Working table size: 120x250mm
4. Printing accuracy: 0.08mm
5. Max printing height: 80mm
6. Power: 220V/110V 50/60hz Power:40w
7. Air pressure: 4-6bar
7. Max printing speed: 1200-1500pcs/hour
8. Machine dimension: 800x370 x700mm
9. Machine NW: 40kg
