Siemens Servo Flat Screen Printing Machine with T Slot Table

Description

Specification

Workbench area: 700mm*1000mm
Max Printing Area: 600mm*900mm
Max Screen Size: 800mm*1200mm
Double Servo Product Max Height: ≦100mm
Workbench Horizontal Precision: ±0.05
Overcolor Print Precision: ±0.01
Printing Pressure: 4.0-6.0Kgf/C㎡
Operation Air Pressure:0.3Mpa-0.5Mpa
Source Power: 2kw
Rated Voltage: 380V 3 phase
Press Two buttons instead Pedal

Main Parts
1)  machine head up and down    , Siemens servo  ,   TaiWan HiWin guide rail .  TB1 Grinding screw .  Japan  DESBDER Planetary reducer
2) machine printing left and right ,Siemens servo  ,   TaiWan HiWin guide rail .  TB1 Grinding screw .  Japan  DESBDER Planetary reducer
3) touch screen :  USA  WEINVIEW
4) PLC :   SIEMENS S7-200
5) pneumatic element :  Japan SMC
6) sensor : TaiWan Fotek
7) electric appliance:  Schneider Electric

8) machine color : customized
