Description
HY-CNC106 is suitable for surface screen printing of various shapes’ bottles such as cylinder, square, oval, triangle, etc.(cosmetics, wine bottles, beverage bottles, and general-purpose containers); suitable for UV and solvent ink printing. It adopt high-precision index, full servo drive system, fast printing speed, stable and reliable quality, convenient and quick debugging, and wider applicability
Typical Features of Automatic Servo Single Color Screen Printing and UV Curing Production Line HY-CNC106
1)Suitable for surface screen printing of various shapes’ bottles such as cylinder, square, oval, triangle, etc.(cosmetics, wine bottles, beverage bottles, and general-purpose containers); suitable for UV and solvent ink printing
2)Adopt high-precision index, full servo drive system, fast printing speed, stable and reliable quality, convenient and quick debugging, and wider applicability
3)10 inch WEINVIEW touch screen (network type)
4)Japan OMRON motion controller
5)The main drive is controlled by Italian SITI reducer with motor and OMRON inverter
6)The product loading and unloading mechanism is driven by 2 sets of OMRON servo motors to run more smoothly and accurately
7)The ball screw and guide rail adopt international famous brands, which have higher precision and longer life.
8)The use of LED electronic UV system (energy saving and environmental protection) is more reasonable, and the operation of employees is easier and safer
9)UV curing is also servo-driven, and the curing time can be set arbitrarily according to the requirements of product printing, which greatly increases the adhesion of the ink
10)It has an independent vacuum system, and the anti-wear products can be manufactured by vacuum suction, which greatly prevents wear during the production process, and ensures that the independent vacuum makes the printing quality more stable.
11)It can print triangles, squares, ellipses and other polygons in the same color at one time
12)The flame treatment adopts servo drive, which can realize the arbitrary adjustment of the speed
13)It uses laser sensor or CCD vision to detect the bottle mouth or pattern positioning point to realize multi-color overprinting and precise control of patterns based on the position of the product surface
14)It is easy to change and debug, without gears, so as to avoid inaccurate color registration after the gear and rack wear, and greatly save the adjustment time
15)It uses 6 stations, which greatly reduces the cost input after the change, so as to save the corresponding cost for the customer
16) CCD post-print inspection system can also be configured, and space reserved for future additions
17) Robot Hand Discharging Mechanical Arm can be customized
18)The main structure design is more reasonable, and it has made major optimizations than the existing domestic machines, and can achieve stable and efficient production
Typical Features of Automatic Servo Single Color Screen Printing and UV Curing Production Line HY-CNC106
1)Suitable for surface screen printing of various shapes’ bottles such as cylinder, square, oval, triangle, etc.(cosmetics, wine bottles, beverage bottles, and general-purpose containers); suitable for UV and solvent ink printing
2)Adopt high-precision index, full servo drive system, fast printing speed, stable and reliable quality, convenient and quick debugging, and wider applicability
3)10 inch WEINVIEW touch screen (network type)
4)Japan OMRON motion controller
5)The main drive is controlled by Italian SITI reducer with motor and OMRON inverter
6)The product loading and unloading mechanism is driven by 2 sets of OMRON servo motors to run more smoothly and accurately
7)The ball screw and guide rail adopt international famous brands, which have higher precision and longer life.
8)The use of LED electronic UV system (energy saving and environmental protection) is more reasonable, and the operation of employees is easier and safer
9)UV curing is also servo-driven, and the curing time can be set arbitrarily according to the requirements of product printing, which greatly increases the adhesion of the ink
10)It has an independent vacuum system, and the anti-wear products can be manufactured by vacuum suction, which greatly prevents wear during the production process, and ensures that the independent vacuum makes the printing quality more stable.
11)It can print triangles, squares, ellipses and other polygons in the same color at one time
12)The flame treatment adopts servo drive, which can realize the arbitrary adjustment of the speed
13)It uses laser sensor or CCD vision to detect the bottle mouth or pattern positioning point to realize multi-color overprinting and precise control of patterns based on the position of the product surface
14)It is easy to change and debug, without gears, so as to avoid inaccurate color registration after the gear and rack wear, and greatly save the adjustment time
15)It uses 6 stations, which greatly reduces the cost input after the change, so as to save the corresponding cost for the customer
16) CCD post-print inspection system can also be configured, and space reserved for future additions
17) Robot Hand Discharging Mechanical Arm can be customized
18)The main structure design is more reasonable, and it has made major optimizations than the existing domestic machines, and can achieve stable and efficient production
Main Specifications of Automatic Servo Single Color Screen Printing and UV Curing Production Line HY-CNC106
Model NO.:
HY-CNC106
Max Print product size (DiameterxLength):
Ø80mm, L230mm
Max. printing speed:
50-60 pcs/min
Registration tolerance:
+/- 0.2mm
Drive:
Mechanical driven
Control system:
OMRON PLC & Touch Screen
Stations:
6 stations
Deionizing device:
1 unit
Flame treating system:
1 unit
Print head:
1 unit
UV system:
1 unit
UV lamp power:
3.6 KW
Motor:
ITALY SITI
Pneumatic parts:
Japan SMC
Photoelectric Sensor:
Japan Keyence
Frequency Converter:
Japan OMRON
Indexer
Japan SANKYO
Electrical Supply:
380V 3phase 50Hz/60Hz
Air requirement:
5-6 bar
Power consumption:
20 KW
Machine Dimension (LxWxH):
4300x4100x2600mm
Weight:
3000 KG
