Description
Features
1.Adopt mature technology Panasonice PLC control system, USA Hypsen sensor.operation is stable and high-speed
2.Using touch-screen control operating system, simple, practical, efficient;
3.Adapt variety shape of object in top labeling;
4.Screw adjustment to suppress body movements accurately;
5.Synchronization chain mechanism ensure labeling smooth and precise calibration;
Parameter:
1.Label width: 20-120mm ( back paper : 120mm)
2.Label length:20-290mm
3.Products Size:
Dia :φ25mm～φ130mm
H:25-300mm
4.Max Outside diameter of label roll: φ260mm
5.Inside diameter of label roll: φ76mm
6.Max Labeling speed: 30-50pcs /min
7.Accuracy of labeling:±1mm
8.Power: 220V/110V 50/60Hz
9.Machine Net Weihgt : 128KG
10. Machine dimension: 1300mm×980mm×900mm(LxWxH)
