Description
The HY-767-3 Three color automatic UV bottle screen printing machine, Print speeds up to 70 bottles per minute, Prints on round & oval containers, Mechanical walking beam indexed, Intelligent UV system save energy consumption, Omron PLC and touch screen controlled, Integrated anti-static blowing and flame treating.
Feture
3 color automatic UV bottle screen printing machine
Fast print speeds up to 4200 bottles per hour
Accurate color to color registration
Prints on round, oval and square bottles
Mechanical driven bottle transport in high stability
Omron PLC and touch screen controlled
Italy SITI brand main motor
Intelligent UV system saves energy consumption
Integrated anti-static dust blowing and bottle surface flame treating
Feture
3 color automatic UV bottle screen printing machine
Fast print speeds up to 4200 bottles per hour
Accurate color to color registration
Prints on round, oval and square bottles
Mechanical driven bottle transport in high stability
Omron PLC and touch screen controlled
Italy SITI brand main motor
Intelligent UV system saves energy consumption
Integrated anti-static dust blowing and bottle surface flame treating
Specifications
Model NO.:
HY-767-3
Round container size:
Diameter: φ10-100mm, Height: 30-260mm
Round container max. print area:
L 260 x W220mm
Oval container size:
R: 10-250mm, Height: 30-260mm
Oval container max. print area:
L 120 x W220mm
Drive:
Mechanical Driven
Control system:
OMRON PLC & Touch Screen
Max. printing capacity:
70 pcs/min
Registration tolerance:
+/- 0.2 mm
Infeed conveyor:
1 unit, length: 2 meters
Deionizing device:
1 unit
Flame treating system:
1 unit, LP gas
Motor:
ITALY SITI
Print head:
1 unit
UV system:
1 unit intelligent UV system, 5KW per each
Outfeed conveyor:
1 unit, Length: 2 meters
Frequency Converter:
OMRON
Pneumatic parts:
FESTO or SMC
Electrical:
380V 3phase 50Hz
Air requirement:
5-7 bar
Air consumption:
85 liter/ minute max. (per color)
Power consumption:
5.4 KW/color x 3
Machine size(LxWxH):
Main machine: (2300x1800x1700mm) x 3
Weight:
1600 KG x 3
